DC Output |
DUAL USB 5V2.4A max |
Operating Tem |
0°C - +55°C |
Efficiency |
level VI |
Storage Tem |
-20°C - +85°C |
Warranty |
3-5 years |
Safety Standard |
IEC62368 IEC60601 IEC61558 |
Certificates |
CB CE UKCA UL/CUL FCC |
CAS FCC Part 15 subpart B Class 2 |
|
Input Voltage |
100Vac~240Vac / 47Hz~63Hz |
AN/NZS CISPR 22:2006 |
|
protection |
over voltage/current protection |
Turn On Time |
less than 3S (110V and full load) |
over temperature protection |
Dielectric Voltage |
3KV |
|
short current protection |
Input Current |
less than 0.2A |
|
Ripple/ Noise |
less than 200Mv at full loading |
Inrush Current |
less than 50A |
Standby power |
less than 0.1w |
Leakage Current |
less than 10mA |
