墙上固定式电源适配器

12-24W 固定式电源适配器

12-24W wall fixed power adapter
input: 100-240VAC
output: see below model list
Inlet: C8 or C6 or C14
Certificates: UL, CCC, FCC, UKCA, CE, ROHS, REACH,RCM, SAA, C-TICK, EAC, S-mark
Color: black or white  optional.
DC jack: 5.5*2.1mm, 4.0*1.7mm, 3.5*1.35mm, 4 pin dim, molex 4pin etc..
size: 73.8*49.5*27mm (exclude the ear)

    SPECIFICATION:

    Item

    12-24W wall fixed Power Adapter

    Model

    SW-00xxxyyy-S10

    Output range

    "xxx" can be 050 to 480 which represent output voltage from 9V to 48V in step on 0.1V

    "yyyy" can be 0010 to 200 which represent output current from 0.1A to 2.0A in step on 0.01A

    Output power: 180W max

    z = A to Z or blank for marketing purpose, no safety concern.

    INPUT

    100-240VAC 50/60Hz

    Output

    SEE MODEL LIST





    Features

    Ripple & Noise

    <120mV

    Energy star level

    Eup 2.0, Doe VI, CEC VI, CoC VI

    Efficiency

    >88%

    Installing

    Available for the system of Safety Class I/II

    Environment

    Operation Temp

    -10 ~ +65, 10 ~ 95% RH non-condensing

    Storage Temp

    -20 ~ +85 (Refer to "Derating Curve")

    Storage Humidity

    20 ~ 90% RH non-condensing

    Vibration

    10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes

    Cooling Method

    by NTC (natural cooling)

    Safety&EMC

    Safety Standard

    UL 62368, ETL 62368, EN 62368, EN 61558

    Safety Approvals

    UL/cUL, ETL, CE, FCC, RoHS, UKCA, PSE, CB, SAA, KC for more
    information, please contact us.

    EMC Stardard

    EMC EMISSION: EN55032 class B (CISPR32), EN61000-3-2,-3, EAC TP TC 020

    EMC IMMUNITY: EN61000-4-2,3,4,5,6,8,11, EN55024; light industry level, criteria A, EAC TP TC 020

    MTBF

    5K hrs min. MIL-HDBK-217F (25)



    Machanicals

    DC Connectors

    USB-C, 5.5x2.1mm, 5.5x2.5mm, 4.0x1.7mm, 3.5x1.35mm and more available

    Dimension

    73.8*49.5*27mm (LxWxH)

    Packing

    300g; 36pcs/10.8Kg/0.056CBM

    MODEL LIST:

    12W Wall fixed POWER ADAPTER

    POWER

    MODEL

    INPUT

    OUTPUT
    VOLT

    OUTPUT
    CURRENT

    Certificates

    inlet

    12W Series

    SW-050200-S10

    100-240VAC

    5.0V

    2.0A

    UL,CE,FCC, RCM,C-TICK, UKCA

    Attached with AC cable

    SW-090130-S10

    9.0V

    1.3A

    SW-120100-S10

    12V

    1.0A

    SW-150080-S10

    15V

    0.8A

    SW-240050-S10

    24V

    0.5A

    SW-480025-S10

    48V

    0.25A



    24W WALL FIXED DESKTOP POWER ADAPTER

    POWER

    MODEL

    INPUT

    OUTPUT
    VOLT

    OUTPUT
    CURRENT

    Certificates

    inlet

    24W Series

    SW-050300-S10

    100-240VAC

    5V

    3.0A

    UL,CE,FCC, RCM,C-TICK, UKCA

    Attached with AC cable

    SW-120150-S10

    12V

    1.5A

    SW-120200-S10

    12V

    2.0A

    SW-150160-S10

    15V

    1.6A

    SW-240100-S10

    24V

    1.0A

    SW-480050-S10

    48V

    0.5A


    DRAWING:
